QUICKIE QS5 X - Folding Wheelchair

QUICKIE QS5 X - Folding Wheelchair

From: £1,500.00 GBP based on assessment.

Experience FreeFold and save over 40% energy with every fold!

Book An Assessment

Speak To An Expert

The QUICKIE QS5 X is a lightweight folding wheelchair designed to enhance your mobility and convenience. Featuring innovative FreeFold technology, it reduces folding forces by over 40%, making it incredibly easy to transport. Built from high-grade 7000-series aluminium, it is exceptionally strong yet lightweight, with a transport weight starting at just 7.3 kg (without rear wheels), making it the lightest aluminium box frame wheelchair available.

Available in Fixed-Front and Swing-Away frame options, the QS5 X caters to various needs. The Fixed-Front provides added stability with permanently attached footrests, while the Swing-Away version ensures easy transfers with footrests that swing aside. Discreet removable LED lights offer enhanced visibility during nighttime use.

Whether you value portability, functionality, or sleek design, the QS5 X combines all these features in one high-performance package.

  • FreeFold Technology: Innovative cross-brace design reduces folding forces, saving over 40% energy with each fold.
  • Lightweight Frame: Weighs from just 7.3 kg (without wheels), making it the lightest aluminium box frame wheelchair available.
  • High-Strength Materials: Constructed from heat-treated 7000 series aluminium for exceptional strength-to-weight ratio.

This price is based on standard configuration only. This item may have multiple additional extras that are not included in the published price. Please contact us for a detailed quote.

View full details

Technical Specifications:

Dimensions

Width: SW + 180/240/270 mm at 0, 2, 4° camber and 25" wheels

Length: 1113 mm

Height: 1020 mm

Seat Width: 340 - 520 mm (in 20 mm steps)

Seat Depth: 340 - 500 mm

Front seat height: 360 - 540 mm

Rear seat height: 350 - 520 mm

Backrest Height: 250 - 500 mm

Frame Angle:

Swing Away: 70/80/90°, Fixed-Front: 75/85°

Maximum Safe Slope: 7°

Rear Wheel Size: 22", 24", 25", 26"

Front Wheel Size: 4", 5", 6", 7"

Performance/Weights

Frame Type: Folding Frame

Version: Swing Away / Fixed Front

Material: 7000 Series Aluminium

Maximum User Weight: 140 kg

Total Weight: Swing Away: From 10.1 kg, Fixed Front: From 9.9 kg

Dismantled Weight: Swing Away: From 7.5 kg (without rear wheels), Fixed Front: From 7.3 kg (without rear wheels)

Transportation Crash Tested? This product has been successfully crash tested and fulfils the performance requirements for ISO

Documentation

Brochure

Owners Manual

Fixed Specifications

feature-item-1
Stores Nationwide
feature-item-2
White Glove Delivery
feature-item-3
Hassle-free Exchange
feature-item-4
Rated Excellent

OVALISED CROSS-BRACE

Ovalised tubing uses 71% of the material compared to a round tube of the same diameter, but due to the properties of the shape it doesn’t sacrifice any strength or stiffness. In-fact, oval tubing is around 15% stiffer than round tubing giving you the best of both worlds.

SWAGED FRAME CONNECTIONS

Swaging is a metal-forming technique in which the metal of one part is formed to fit around another, increasing stiffness and eliminating the need for additional connecting parts or screws. This reduces weight, minimises wear points, and eliminates frame movement.

FORGED CASTOR LINK

Traditionally, castor links are clamped to the front of the wheelchair frame, adding weight and causing energy loss through frame vibration. Forging the castor link to the front frame reduces weight and allows more energy to pass through to propulsion instead of being lost in frame flex.

TRAVEL COMPANION

The QS5 X is perfect for those who need a folding wheelchair to store whilst travelling. It folds compact enough to fit into a car roof box, and also has removable wheels and a half-folding backrest for those who need to lift the chair across their body and independently car transfer.

Folding mobility scooter

FOLD-N-LOCK

Tired of wheelchairs that unfold whilst lifting? Just pull the QS5 X’s seat-sling upwards and the Fold-N-Lock activates to keep your chair safely folded. It’s so easy, you can do it with just one hand! And, when you’re ready to un-fold, just press the release lever and push- down on both sides of the frame until the seat rail smoothly locks into place. Say goodbye to unfolding mishaps and hello to easy lifting!

SHOW OFF YOUR STYLE

Personalise your QS5 X with a range of 22 vibrant frame colours and 4 anodized caster fork and rim colours to suit your taste. Whether you’re looking for a subtle or vibrant look, QS5 X’s colour options have got you covered.
